AJ 340 Waterjet

Lightweight, compact and highly efficient

The AJ 340 is a lightweight, compact and highly efficient commercial waterjet. Cavitation limits are the highest in class due to Alamarin-Jets leading hydrodynamic design, without reducing top speed capabilities. AJ 340 is suitable for large military and commercial fast craft, as well as pleasure craft applications.

Features include:

  • Conical impeller housing
  • Oil lubricated main bearing
  • Water lubricated rear bearing
  • Integrated oil cooler
  • 0° and 5° installation angle options
  • Universal hydraulic system

AJ 340 is compatible with AJ ACU and AJ SIGMA Controls

ISO

9001

ISO

14001

ISO

45001
AJ 340 Waterjet
Dimensions 0° Arrangement 5° Arrangement
A
850 mm / 33,46 in 760 mm / 29,94 in
B
2113 mm / 83,20 in
2140 mm / 84,25 in
C
763 mm / 30,04 in 763 mm / 30,04 in
D 580 mm / 22,84 in 580 mm / 22,84 in
E 859 mm / 33,82 in 877 mm / 34,51 in

Specifications

  • Pump type
    Mixed flow

  • Jet construction
    Aluminium / Stainless Steel

  • Max impeller diameter
    335mm / 13.2″

  • Max impeller shaft RPM
    3300 1/min

  • Max input power
    550 kW / 750 HP

  • Jet weight
    245kg / 540lbs

  • Reverse deflector control
    Hydraulic

Contact us for more information

If you want to learn more about this or our other models for your particular specifications and application, we are here to help you.
