The newest jet in the COMBI-FRAME series
The AJ 285 is the newest jet in the COMBI-FRAME series. The patented Combi-Frame technology allows designers, builders and owners maximum flexibility when locating the position of the propulsion system within the vessel.
Choosing between 2 different hull installation inserts allows the jet to be installed either in LONG TAIL or SHORT TAIL configuration. Following the success of AJ 245 many customers requested the combi-frame installation method for larger, more powerful vessels. AJ 285 is suitable for engines up to 500HP. Applications include workboats, military vessels, pleasure craft and many more.
- Conical impeller housing
- Grease lubricated main bearing
- Water or grease lubricated rear bearing
- Integrated oil cooler
- Patented COMBI FRAME installation method
- Integrated steering cylinder
- Universal hydraulic system
AJ 285 is compatible with AJ ACU and AJ SIGMA Controls.
|Dimensions||Long tail||Short tail|
|A||503 mm / 19,82 in||504 mm / 19,83 in|
|B||1637 mm / 64,45 in
||1637 mm / 64,45 in
|C||698 mm / 27,47 in||698 mm / 27,46 in|
|D||454 mm / 17,87 in||454 mm / 17,87 in|
|E||327 mm / 12,88 in||725 mm / 28,55 in|
